Chapter II-12 — Graphs

II-310

Graph Shortcuts

Action Shortcut (Macintosh) Shortcut (Windows)

To autoscale a graph Press Command-A. Press Ctrl+A.

To modify the appearance

or front-to-back drawing

order of a trace

Press Control and click the trace to get

a contextual menu.

Press Shift-Control to modify all

traces.

Double-click the trace to summon a

dialog.

Right-click the trace to get a

contextual menu.

Press Shift while right-clicking to

modify all traces.

Double-click the trace to summon a

dialog.

To modify the appearance

of an axis, axis labels, grid

lines, tick marks

Press Control and click the axis.

Press Shift-Control to modify all axes.

Double-click an axis to summon a

dialog.

Right-click the axis.

Press Shift and right-click to modify

all axes.

Double-click an axis to summon a

dialog.

To modify the appearance

of a contour plot

Control-click and choose Modify

Contour from the contextual menu or

press Shift and double-click the contour

plot.

See also Chapter II-15, Image Plots.

To set background colors Press Control and click in the graph

body, away from any traces.

Press Ctrl and click in the graph body,

away from any traces.

To set the range of an axis Double-click tick mark labels to

summon a dialog.

Double-click tick mark labels to

summon a dialog.

To pan the graph Press Option and drag the body of the

graph.

Press Shift also to constrain the

direction of panning.

Press Alt and drag the body of the

graph.

Press Shift also to constrain the

direction of panning.

To offset a trace Click and hold the trace for about a

second, then drag. You can avoid

inadvertently triggering this feature by

pressing Caps Lock before clicking a

trace.

Click and hold the trace for about a

second, then drag. You can avoid

inadvertently triggering this feature by

pressing Caps Lock before clicking a

trace.

To adjust the position of an

axis or axis label

Drag the axis or label. Drag the axis or label.

To change a graph margin Press Option and click the axis and

drag. Drag beyond edge of graph to

return to default position.

Press Option and double-click an axis or

just double-click outside of the graph

body and axes to summon a dialog.

Press Alt and click the axis and drag.

Drag beyond edge of graph to return

to default position.

Press Alt and double-click an axis or

just double-click outside of the graph

body and axes to summon a dialog.

To change an axis label Double-click the label to summon a

dialog.

Double-click the label to summon a

dialog.
